Description
XD6 RGB ELITE LCD
PUMP / RESERVOIR COMBO
BUILT TO IMPRESS
POWER MEETS PRECISION
The HYDRO X SERIES XD6 RGB ELITE LCD features the new FlowDrive Max pump, delivering a higher overall flow rate and improved performance at lower RPMs. Its vibrant LCD screen, the same found on our award-winning AIO coolers, adds a bold visual touch to any custom cooling setup.
MAKE IT YOUR OWN
REAL-TIME PUMP DISPLAY
Showcase your creativity and personalize your build with real-time coolant temperature, animated GIFs, memes, or your team’s logo on a custom 30 FPS IPS LCD screen with 480×480 resolution, ultra-bright 600cd/m2 backlight, and 24-bit true color depth.
DISPLAY SCREEN PREVIEW
THE FUTURE OF DIY PC BUILDING
iCUE LINK SMART COMPONENT ECOSYSTEM
Redefine the way you build a DIY PC with a groundbreaking single-cable technology that automatically detects and configures your PC fans, CPU coolers, and other internal components.
THE EASY WAY TO BUILD A PC
Reduce cable clutter with a network of smart, interconnected components.
LINK YOUR COMPONENTS
The iCUE LINK ecosystem uses a single connector for all iCUE LINK devices.
UNITE YOUR SETUP
Each component connects directly to the next, creating a chain of devices.
PRO FLOW
CUSTOM COOLING TOTAL CONTROL
The XD6 RGB ELITE features a high-performance FlowDrive Max pump and integrated coolant temperature sensor to provide outstanding cooling performance and precise control of your pump speed and flow rate.
LIVING COLOR
STUNNING RGB LIGHTING
Illuminate your coolant and reservoir with 22 individually addressable RGB LEDs for a dazzling display of glorious lighting. Each RGB LED is easily customizable with CORSAIR iCUE software, which allows you to choose from a wide array of eye-catching lighting patterns.
FLEXIBLE PERFECTION
EASY AND FLEXIBLE INSTALLATION
The XD6 RGB ELITE features multiple G1/4 ports and practical additions for easy setup, including an integrated fill port, a 24-pin power supply jumper bridge, and a rubberized mounting system with adjustable brackets for flexible installation in multiple locations.
CUSTOM COOLING CONFIGURATOR
Take out all the guesswork and create the custom cooling system of your dreams.
With thousands of components and millions of hardware combinations, it’s easy to pick, tweak, and personalize your custom cooling system, with a detailed render of how your future loop will look.DESIGN YOUR LOOP
THREE-YEAR WARRANTYWORLD-CLASS SUPPORTOur award-winning service means you can enjoy your gear worry-free.
GET STARTED FAST WITH iCUE
See how easy it is to install your new CORSAIR components and set things up in iCUE software.
Tech Specs
| Lighting | RGB |
|---|---|
| Compatible Materials | Only mix with other copper / brass products |
| Port Thread | G1/4″ BSPP |
| Max Operating Temperature | 60°C coolant temperature |
| Pump Voltage | 12V |
| Max Hydraulic Performance | 800L/h at 2.1m pressure head (1500L/H theoretical max) |
| Pump Type | CORSAIR PWM |
| Fluid Chamber Material | Nylon |
|---|---|
| Compatible Coolants | CORSAIR XL or equivalent |
| Color | STEALTH GREY |
| Cooling Warranty | 3 Year |
| Model | Pump / Reservoir Combo |
| Weight | 1.319kg |
